50DP60-01-1-AJN by grayhill
Image is representational - see mfr. specs

50DP60-01-1-AJN

Grayhill

A Series 50 single-deck rotary switch featuring a 60° angle of throw, 1 pole, adjustable stops, non-shorting contacts, and PC mount terminals. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 50DP60-01-1-AJN is a Series 50 single-deck rotary switch with PC mount terminals for direct board assembly. This switch is configured with a 60° angle of throw, a single pole, and non-shorting contacts. It is rated to switch 200 mA at 28 Vdc for 25,000 cycles and can continuously carry 6 amperes. A key feature is its adjustable stop mechanism, which allows the user to set the number of active positions from two to six. This versatility makes the switch ideal for prototyping, test equipment, and other applications where the number of selectable circuits may vary.

Search Keywords: 50DP60011AJN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
50DP60-01-1-AJN
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
N/A
Pole Throw Configuration:
SP6T
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 29.52 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount/Through Hole
Body Orientation:
Straight
Terminal Type:
PC Pins
Angle of Throw:
60 °
Contact Rating @ Voltage:
0.2@28VDC A

IN STOCK: 72

Can Ship immediately

Factory Lead-Time 12 Weeks

Qty
Unit Price
1
$31.21
5
$29.19
10
$27.85
25
$27.01
50
$25.86
100
$20.67
250 +
$18.91
Log in for special pricing Click for Quote Price Match Request
