50A36-01-1-03N by grayhill
Image is representational - see mfr. specs

50A36-01-1-03N

Grayhill

A Series 50 single-deck rotary switch with one pole, three positions, a 36° angle of throw, and non-shorting contacts. ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 50A36-01-1-03N is a Series 50 single-deck rotary switch designed for manual circuit selection. This switch is configured with one pole, three positions, a 36° angle of throw, and non-shorting wiping contacts. It features solder lug terminals and is built for a life expectancy of 25,000 cycles, capable of switching loads up to 200 mA at 28 Vdc resistive. With a continuous contact carry rating of 6 amperes and a compact 0.5-inch diameter, it is well-suited for applications in instrumentation, test equipment, and communication devices where space is limited but reliable performance is critical.

Search Keywords: 50A3601103N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
50A36-01-1-03N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
3
Pole Throw Configuration:
SP3T
Actuator Length:
9.53 mm
Dimension:
12.7 x 12.7 x 35.46 mm
Actuator Style/Diameter:
Flatted Shaft/3.18
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
36 °
Contact Rating @ Voltage:
0.2@28VDC A

IN STOCK: 25

Can Ship immediately

Factory Lead-Time 12 Weeks

Qty
Unit Price
1
$45.73
5
$35.70
10
$24.50
25
$23.01
50
$22.51
100
$21.80
250 +
$21.69
