44M90-03-2-02N by grayhill
Image is representational - see manufacturer specifications
Grayhill Authorized Distributor

44M90-03-2-02N

The 44M90-03-2-02N is a military-qualified, 3-deck rotary switch with a 90° angle of throw, 2 poles per deck, and 2 non-shorting positions per pole. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 44M90-03-2-02N is a Series 44 multi-deck rotary switch designed for high-reliability applications. This military-qualified switch features 3 decks, each configured for 2 poles and 2 non-shorting positions, operating with a 90-degree angle of throw and continuous rotation. The switch is rated to carry 10 amps continuously and has a mechanical life expectancy of 100,000 cycles. Built with diallyl phthalate materials and qualified to MIL-DTL-3786/SR04 standards for an operating temperature range of -65°C to 85°C, it provides durable switching for military and other demanding equipment.

Search Keywords: 44M9003202N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
44M90-03-2-02N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Number of Positions:
2
Pole Throw Configuration:
DPDT
Actuator Length:
11.1 mm
Dimension:
29.51mm x 31.07mm x 65.81 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder Lug
Angle of Throw:
90 °
Contact Rating @ Voltage:
5@115VAC A

FREQUENTLY ASKED QUESTIONS

Is 44M90-03-2-02N RoHS compliant?

Yes, 44M90-03-2-02N is RoHS compliant.

What is the lead time for 44M90-03-2-02N?

The standard lead time for 44M90-03-2-02N is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 3

Can Ship immediately

MOQ for out of Stock Qty: 3

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$183.38
3
$171.48
5
$166.09
8
$159.25
10 +
$157.67
