44HS45-01-1-04N by grayhill
Image is representational - see manufacturer specifications
Grayhill Authorized Distributor

44HS45-01-1-04N

Switch Rotary SP4T 4 Flatted Shaft Solder Lug 5A 115VAC 28VDC ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 44HS45-01-1-04N is a Series 44 multi-deck rotary switch manufactured by Grayhill, designed for rugged industrial and military applications requiring reliable switching control. This switch features a 1-inch diameter with a 45-degree angle of throw, 1 amp contact rating, and non-shorting contact configuration, meeting MIL-S-3786/04 military qualification standards. The switch incorporates three decks with two poles per deck, providing flexible circuitry options with a 0.625-inch (15.88 mm) diameter bushing and integral assembly nut. Key dimensional specifications include a 0.375-inch (9.53 mm) shaft diameter, 0.437-inch (11.10 mm) stud projection, and a non-turn tab measuring 0.125 by 0.031 inches. The rugged construction ensures reliable operation throughout the equipment's service life, making it suitable for control panels, instrumentation systems, and military-grade switching applications where durability and precision are essential.

Search Keywords: 44HS4501104N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
44HS45-01-1-04N
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Number of Positions:
4
Pole Throw Configuration:
SP4T
Actuator Length:
11.1 mm
Dimension:
29.51 x 31.07 x 48.24 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
45 °
Contact Rating @ Voltage:
5@115VAC A

FREQUENTLY ASKED QUESTIONS

Is 44HS45-01-1-04N RoHS compliant?

Yes, 44HS45-01-1-04N is RoHS compliant.

What is the lead time for 44HS45-01-1-04N?

The standard lead time for 44HS45-01-1-04N is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 5

Can Ship immediately

MOQ for out of Stock Qty: 3

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$136.84
3
$136.50
5
$122.85
8
$107.49
10 +
$105.34
