44D30-02-2-AJN by grayhill
Image is representational - see manufacturer specifications
Grayhill Authorized Distributor

44D30-02-2-AJN

A Series 44, 2-deck, 2-pole per deck rotary switch featuring a 30° angle of throw, non-shorting contacts, and adjustable stops for 2 to 6 positions. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 44D30-02-2-AJN is a multi-deck rotary switch from the Series 44 family, designed for versatile circuit selection. It is configured with 2 decks and 2 poles per deck, operating with a 30° angle of throw between positions. A key feature is its adjustable stop mechanism, which allows the user to configure the switch for 2 to 6 positions per pole. The switch utilizes non-shorting (break-before-make) contacts, preventing momentary connection between adjacent positions during rotation. With its rugged construction and flexible configuration, this switch is ideal for prototyping, test equipment, and industrial control panels where reliable and adaptable circuit control is required.

Search Keywords: 44D30022AJN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
44D30-02-2-AJN
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
N/A
Pole Throw Configuration:
4P6T
Actuator Length:
11.1 mm
Dimension:
29.51 x 31.07 x 57.02 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
1@115VAC 28VDC A

FREQUENTLY ASKED QUESTIONS

Is 44D30-02-2-AJN RoHS compliant?

Yes, 44D30-02-2-AJN is RoHS compliant.

What is the lead time for 44D30-02-2-AJN?

The standard lead time for 44D30-02-2-AJN is approximately 29 days. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 90   can ship 10/26/26

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
1
$107.64
5
$99.61
10
$96.73
20
$91.42
50
$88.98
100 +
$66.74
