29-1-BLK by grayhill
Image is representational - see manufacturer specifications
Grayhill Authorized Distributor

29-1-BLK

The 29-1-BLK is a straight-skirt style, panel-mount binding post for electrical terminations. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 29-1-BLK is a Series 29 straight-skirt binding post designed for space-saving electrical connections. It is rated for 15 Amps continuously at 120 Vdc with a maximum temperature rise of 20°C and has a voltage breakdown of 1500 Vac. Constructed with nickel-plated brass metal parts and thermoset plastic insulation, it mounts into a 3/8-inch diameter hole on panels up to 3/16-inch thick. Features include a #10-32 UNEF-2A thread, a flush cross-hole to prevent wire crimping, and an integral solder stud, making it suitable for various test and instrumentation applications.

Search Keywords: 291BLK

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Grayhill
Part No:
29-1-BLK
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509030
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

FREQUENTLY ASKED QUESTIONS

Is 29-1-BLK RoHS compliant?

Yes, 29-1-BLK is RoHS compliant.

What is the lead time for 29-1-BLK?

The standard lead time for 29-1-BLK is approximately 12 days. In-stock quantities ship from Master Electronics.

IN STOCK: 22

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$9.47
25
$8.58
50
$8.19
100
$7.96
250
$7.52
500
$7.32
1,000 +
$7.22
