C4D0112N-A by electroswitch
Image is representational - see mfr. specs

C4D0112N-A

Electroswitch

The C4D0112N-A is a single-pole, 12-position, non-shorting rotary switch with a 30° indexing angle and adjustable stops. ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The C4D0112N-A is a single-pole, 12-position non-shorting rotary switch from the C4 Series, featuring a versatile, fully enclosed design. It is constructed with diallyl phthalate insulation and silver-plated brass contacts to protect against environmental contaminants and ensure reliable operation. The switch is rated to make and break a resistive load of 0.5A at 28 VDC or 0.3A at 125 VAC, and has a current carrying capacity of 15 amps. With a minimum mechanical life of 25,000 cycles and adjustable stops, this switch is ideal for applications requiring durable and precise multi-position circuit selection.

Search Keywords: C4D0112NA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Electroswitch
Part No:
C4D0112N-A
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536509020
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Number of Positions:
12
Pole Throw Configuration:
SP12T
Actuator Length:
12.7 mm
Dimension:
38.1 x 38.1 x 42.34 mm
Actuator Style/Diameter:
Flatted Shaft/6.35
Mounting:
Panel Mount
Body Orientation:
Straight
Terminal Type:
Solder
Angle of Throw:
30 °
Contact Rating @ Voltage:
0.5@28VDC A

IN STOCK: 66

Can Ship immediately

Factory Lead-Time 6 Weeks

Qty
Unit Price
1
$36.97
5
$26.97
10
$25.00
25
$22.68
50
$21.22
100
$19.85
250 +
$17.75
Log in for special pricing Click for Quote Price Match Request
