GBB-10-R by eaton electronics / bussmann
Image is representational - see manufacturer specifications
Eaton Electronics / Bussmann Authorized Distributor

GBB-10-R

Fuse Miniature Very Fast Acting 10A 250V Holder Cartridge 6.3 X 32mm Ceramic Cardboard Carton ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

GBB-10-R is a very fast-acting ceramic tube fuse rated at 10A, designed for reliable overcurrent protection in electronic circuits. It features a 1/4" x 1-1/4" (6.35 x 31.75 mm) physical size with ceramic tube and nickel-plated brass endcap construction, and includes axial leads for PCB mounting. The fuse is rated for 250Vac and 125Vdc operation, with AC interrupting ratings of 200A at 250Vac and 10,000A at 125Vac, and a DC interrupting rating of 10,000A at 125Vdc. It exhibits a typical DC cold resistance of 0.00934O and a typical voltage drop of 0.0877V. This UL Recognized and CSA Component Accepted fuse is ideal for applications requiring fast response to overcurrent conditions, providing dependable circuit protection.

Search Keywords: GBB10R

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Eaton Electronics / Bussmann
Part No:
GBB-10-R
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536100040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
5
Package Type:
OTHER
Type:
Miniature
Fuse Size:
6.3 x 32 mm
Acting:
Very Fast
Current Rating:
10 A
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
125 V
Fuse Material:
Ceramic
Mounting:
Holder

FREQUENTLY ASKED QUESTIONS

Is GBB-10-R RoHS compliant?

Yes, GBB-10-R is RoHS compliant.

What is the lead time for GBB-10-R?

The standard lead time for GBB-10-R is approximately 24 weeks. In-stock quantities ship from Master Electronics.

  Different packaging options available.  See Alternatives

IN STOCK: 0

Minimum Order Quantity: 5

Multiple: 5

Factory Lead-Time 24 Weeks
