ULV4F23SS331

Name: ULV4F23SS331 ESwitch Push Button Switches
Brand: ESwitch
SKU: 48584298
Availability: InStock

The ULV4F23SS331 is an SPDT illuminated push-button switch with a green ring light, rated for 3A at 250VAC. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The ULV4F23SS331 is an SPDT (Single Pole Double Throw) illuminated push-button switch designed for panel mounting. It has a cUL electrical rating of 3A at 250VAC and features silver contacts with a maximum contact resistance of 50mΩ. Constructed with a stainless steel housing and actuator, the switch is built for durability, offering a mechanical life of 500,000 cycles and an electrical life of 50,000 cycles at full load. It operates in temperatures from -20°C to 55°C and is sealed for IP67 ingress protection against dust and water. The integrated 3V green LED ring provides clear status indication, making it suitable for industrial controls, medical equipment, and other demanding applications.

Product Highlights:

Potential Applications:

Search Keywords: ULV4F23SS331

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

E-Switch

Part No:

ULV4F23SS331

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536509065

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
