TL3301BF160QJ by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

TL3301BF160QJ

The TL3301BF160QJ is a 6.00mm x 6.00mm SPST tactile switch rated for 12VDC at 50mA. ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The TL3301BF160QJ is a Single Pole, Single Throw (SPST) tactile switch. It is rated for 12VDC at 50mA and requires an operating force of 160 ± 50 grams with a travel of 0.25mm. Featuring silver contacts, the switch maintains an initial contact resistance of 100 milliohms maximum. This component is designed for durability, offering a minimum mechanical and electrical life of 100,000 cycles. Its compact 6.00mm square body and RoHS compliance make it suitable for a wide range of electronic devices requiring a reliable user input interface.

Search Keywords: TL3301BF160QJ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
TL3301BF160QJ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
600
Package Type:
REEL
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Round Button
Operating Force:
1.57 N
Contact Rating @ Voltage:
0.05@12VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
J-Lead
Seal Location:
N/A

FREQUENTLY ASKED QUESTIONS

Is TL3301BF160QJ RoHS compliant?

Yes, TL3301BF160QJ is RoHS compliant.

What is the lead time for TL3301BF160QJ?

The standard lead time for TL3301BF160QJ is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 5,074

Can Ship immediately

On Order: 5,674   can ship 12/10/26

Minimum Order Quantity: 600

Multiple: 600

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
600
$0.2637
1,200
$0.2537
3,000
$0.2439
5,400
$0.2433
7,800
$0.2427
25,200
$0.2421
50,400 +
$0.2415
Reel Package
