RP8300B2M1CEBLKBLKNIL by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

RP8300B2M1CEBLKBLKNIL

The RP8300B2M1CEBLKBLKNIL is a momentary, single-pole single-throw (SPST) pushbutton switch designed for panel mounting. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The RP8300B2M1CEBLKBLKNIL is a momentary SPST pushbutton switch featuring a black plated metal housing and a black actuator. It offers a contact rating of up to 500mA at 48VDC and utilizes gold over silver contacts for reliable switching. Engineered for durability, this switch provides an electrical life of 500,000 cycles at full load and operates across a temperature range of -30°C to +85°C. Its IP67 front panel seal rating makes it ideal for use in harsh environments, including industrial controls, medical equipment, and outdoor applications where protection from dust and water is required.

Search Keywords: RP8300B2M1CEBLKBLKNIL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
RP8300B2M1CEBLKBLKNIL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
70
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
On Off
Contact Rating @ Voltage:
0.5A@48 VAC
Actuator Style:
Button
Illumination:
N/R
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
17.5 x 17.5 x 19.9 mm

FREQUENTLY ASKED QUESTIONS

Is RP8300B2M1CEBLKBLKNIL RoHS compliant?

Yes, RP8300B2M1CEBLKBLKNIL is RoHS compliant.

What is the lead time for RP8300B2M1CEBLKBLKNIL?

The standard lead time for RP8300B2M1CEBLKBLKNIL is approximately 12 days. In-stock quantities ship from Master Electronics.

IN STOCK: 40

Can Ship immediately

On Order: 280   can ship 10/26/26

Minimum Order Quantity: 5

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
5
$6.821
25
$5.764
70
$5.347
140
$5.076
280
$4.831
560
$4.619
1,050
$4.435
2,520 +
$4.424
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
