RP8100B2M1CEBLKBLKRED by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

RP8100B2M1CEBLKBLKRED

A panel-mount, momentary push-button switch with an SPST circuit and red LED illumination. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The RP8100B2M1CEBLKBLKRED is a momentary, panel-mount push-button switch featuring an SPST OFF-(ON) circuit and an integrated red LED. It is rated for 125mA at 125VAC or 100mA at 50VDC, with gold over silver contacts ensuring a long electrical life of 500,000 cycles at full load. This switch is designed for durability, operating in temperatures from -30°C to +85°C and featuring an IP67 seal rating for the front panel. With an operating force of 350 gf and a travel of 1.5mm, it provides reliable tactile feedback for applications in industrial controls, telecommunications, and instrumentation.

Search Keywords: RP8100B2M1CEBLKBLKRED

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
RP8100B2M1CEBLKBLKRED
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Mounting:
Panel Mount13759
Pole Throw Configuration:
SPST13761
Bushing Type:
Threaded13741
Switch Configuration:
OFF (ON)13768
Contact Rating @ Voltage:
0.12513752A@125VAC
Actuator Style:
Curved Round Button13737
Illumination:
Red,LED
Terminal Type:
Solder Lug13770
Body Orientation:
Straight13740
Dimension:
17.5mm x 17.5mm x 21.313763mm

FREQUENTLY ASKED QUESTIONS

Is RP8100B2M1CEBLKBLKRED RoHS compliant?

Yes, RP8100B2M1CEBLKBLKRED is RoHS compliant.

What is the lead time for RP8100B2M1CEBLKBLKRED?

The standard lead time for RP8100B2M1CEBLKBLKRED is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

On Order: 200   can ship 12/21/26

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
50
$6.02
100
$5.75
250
$5.50
500
$4.68
1,000
$4.21
2,500
$3.30
5,000
$2.83
7,500 +
$2.82
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
