PV6F24011-311 by e-switch
Image is representational - see manufacturer specifications
E-Switch Authorized Distributor

PV6F24011-311

Switch Push Button OFF (ON) SPST Flat Button 2A 48VDC Momentary Contact Solder Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

PV6F24011-311 is an illuminated pushbutton switch designed for panel-mount applications with a momentary SPST (Single Pole Single Throw) contact configuration. The switch features a red ring illumination powered at 1.8V, a black anodized flat actuator, and silver contact material rated for 2A at 48VDC. It is housed in an M16x1.0 threaded body with a recommended panel cutout diameter of 16.00 mm and supports a maximum panel thickness of 10 mm. The switch delivers reliable performance across an operating temperature range of -40°C to +85°C, with an electrical life of 50,000 make-and-break cycles at full load, contact resistance of 50 mO maximum at 1A 12VDC, and IP65 ingress protection. This switch is ideal for industrial control panels, machinery interfaces, and applications requiring visual feedback with robust electrical performance.

Search Keywords: PV6F24011311

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
E-Switch
Part No:
PV6F24011-311
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Mounting:
Panel Mount
Pole Throw Configuration:
SPST
Bushing Type:
Threaded
Switch Configuration:
Off (On)
Contact Rating @ Voltage:
2A@48 VDC
Actuator Style:
Flat Button
Illumination:
Red,Lamp
Terminal Type:
Solder
Body Orientation:
Straight
Dimension:
18 x 18 x 21.5 mm

FREQUENTLY ASKED QUESTIONS

Is PV6F24011-311 RoHS compliant?

Yes, PV6F24011-311 is RoHS compliant.

What is the lead time for PV6F24011-311?

The standard lead time for PV6F24011-311 is approximately 10 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 80

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
5
$12.14
40
$11.20
80
$10.89
120
$10.71
280
$10.33
520
$9.29
1,000 +
$8.57
Supplier's Standard Package
