100SP1T1B1M1QE
E-SwitchToggle Switch - SPDT - On-None-On - 120VAC/28VDC - 5A - Silver Plated Contacts - Solder Lugs - 1/4-40UNS x .350" Bushing - No Hardware ...
DESCRIPTION
The 100SP1T1B1M1QE is a three-position rotary switch featuring a single-pole double-throw (SPDT) circuit with silver contact material designed for general-purpose switching applications. The switch is rated for 2 A at 250 VAC, 5 A at 120 VAC, or 5 A at 28 VDC, with an insulation resistance of 1,000 MO minimum and a dielectric strength of 1,000 V RMS at sea level. It is rated for 6,000 make-and-break cycles at full load and operates reliably across a temperature range of -40°C to +85°C. The switch features a panel-mount design with a 1/4-40 UNS-2A threaded stud and is sealed with epoxy for environmental protection. Common applications include industrial control panels, instrumentation, and consumer equipment where reliable multi-position switching is required.
Search Keywords: 100SP1T1B1M1QE
SPECIFICATIONS
STEP File
Datasheet
