657-1504-103F by dialight
Image is representational - see mfr. specs

657-1504-103F

Dialight

The 657-1504-103F is a watertight, red LED panel mount indicator with a flat, tinted diffused lens, designed for 24 VDC operation. ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 657-1504-103F is a red LED panel mount indicator from the 657 Watertight Series. It is designed to operate on a 24 VDC supply, drawing 20 mA of current and producing a typical luminous intensity of 650 mcd. This indicator features a durable polycarbonate housing and a flat, tinted diffused lens, ensuring reliability in harsh conditions with IP67 and NEMA 4X ratings. It operates over a temperature range of -35°C to +65°C and comes with 6-inch, 18 AWG wire leads for electrical connection. Its robust, watertight construction makes it ideal for industrial control panels, heavy-duty vehicles, marine equipment, and other demanding applications.

Search Keywords: 6571504103F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
657-1504-103F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8531909001
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
BAG
Mounting:
Panel
Dimension:
33.5 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
24 V
Color:
Red
Peak Wavelength:
N/A
Lens Shape Type:
Circular
Lens Appearance:
Colored Diffused
Lens Dimensions:
N/A
Intensity:
N/A
Viewing Angle:
N/A
Maximum Forward Current:
19(Typ) mA

IN STOCK: 100

Can Ship immediately

Minimum Order Quantity: 5

Multiple: 5

Factory Lead-Time 20 Weeks

Qty
Unit Price
5
$21.44
25
$15.73
50
$15.39
100
$13.59
250
$13.56
500
$12.83
1,000 +
$12.80
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
