Image is representational - see mfr. specs

564-0100-222F

A 3-position, through-hole circuit board indicator (CBI) featuring three green diffused LEDs in a single block housing. ...

Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 564-0100-222F is a 3-position, right-angle, through-hole circuit board indicator designed for status indication on PCBs. It integrates three green diffused LEDs into a single black housing, providing a uniform look and simplifying assembly. Each LED has a typical luminous intensity of 12.6 mcd at a 20 mA forward current and a typical forward voltage of 2.1 V. The LEDs feature a 60-degree viewing angle and a typical dominant wavelength of 565 nm, producing a distinct green light. This component is ideal for applications requiring multiple status indicators in a compact space, such as network equipment, storage devices, and industrial control panels.

Product Highlights:

Potential Applications:

Search Keywords: 5640100222F

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Dialight

Part No:

564-0100-222F

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8541402000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
