559-3001-007F by dialight
Image is representational - see mfr. specs

559-3001-007F

Dialight

The 559-3001-007F is a 2-leaded, bi-color (Red/Green) snap-in LED panel mount indicator designed for a 0.250-inch mounting hole. ...

Datasheet
RoHS Non-Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 559-3001-007F is a bi-color, 2-leaded snap-in LED indicator for panel mounting. It emits red light with a peak wavelength of 660 nm and green light at 565 nm, with typical luminous intensities of 90 mcd and 40 mcd, respectively. The indicator operates with a typical forward current of 20 mA and has corresponding forward voltages of 1.8V for red and 2.1V for green. It features a 60-degree viewing angle and comes with 14-inch, 24 AWG wire leads. This RoHS compliant indicator operates over a wide temperature range of -55°C to +100°C, making it suitable for demanding applications like data-center infrastructure, communications equipment, and electronic test instruments.

Search Keywords: 5593001007F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
559-3001-007F
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541402000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BAG
Mounting:
Panel
Dimension:
15.88(Max) x 7.14 mm
Type:
Bi-Color
Maximum Forward Voltage per Color:
2.1(Typ)/1.8(Typ) V
Color:
Green/Red
Peak Wavelength:
565/660 nm
Lens Shape Type:
Circular
Lens Appearance:
N/A
Lens Dimensions:
N/A
Intensity:
40,90 mcd
Viewing Angle:
60 °
Maximum Forward Current:
30/40 mA

IN STOCK: 1,235

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 15 Weeks

Qty
Unit Price
100
$1.45
300
$1.40
500
$1.39
1,000 +
$1.38
Suppliers Standard Package
