559-0103-001F by dialight
Image is representational - see mfr. specs

559-0103-001F

Dialight

559 LED PMI 0.250" Red, Tintd, Diff, 12 VDC, Straight Leads ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 559-0103-001F is a snap-in LED panel mount indicator from Dialight's 559 series, featuring a red LED with 12V integral resistor for direct connection without external components. This indicator offers a peak wavelength of 635 nm with typical intensity of 8 mcd and forward current of 13 mA, operating reliably across a temperature range of -55°C to +100°C. The device features a 0.250" (6.35 mm) mounting hole with straight terminals for wire wrapping or 24 AWG lead wire connections, housed in black UL94V-0 flammable-rated plastic. It is ideal for applications in electronic test and measurement instruments, communications testing equipment, data-center infrastructure, and hand-held devices where reliable visual indication is required.

Search Keywords: 5590103001F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Dialight
Part No:
559-0103-001F
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541402000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
BAG
Mounting:
Panel
Dimension:
15.88(Max) x 7.14 mm
Type:
Uni-Color
Maximum Forward Voltage per Color:
12(Typ) V
Color:
Red
Peak Wavelength:
635 nm
Lens Shape Type:
Circular
Lens Appearance:
Colored
Lens Dimensions:
5x5x5.33 mm
Intensity:
8 mcd
Viewing Angle:
60 °
Maximum Forward Current:
15 mA

IN STOCK: 1,050

Can Ship immediately

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
25
$1.241
250
$1.021
500
$0.979
1,000
$0.940
2,500
$0.904
5,000
$0.881
7,500
$0.871
10,000 +
$0.869
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
