20114-84

Electromechanical Relay 110VDC 10KOhm 10A DPDT (35.05x35.05x50.8)mm Socket General Purpose Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

20114-84 is a 10 Amp plug-in octal base general purpose relay with DPDT (Double Pole Double Throw) contact configuration and 110 VDC coil voltage. The relay features a Class F coil insulation system rated for 155°C total temperature and employs a coil molded in Rynite® PET for environmental protection. Contact materials include 3/16" diameter moveable silver cadmium oxide and 3/16" diameter stationary fine silver with gold flash standard on all contacts. The relay is rated for 1/2 HP or 10 Amp at 277 VAC, 10 Amp at 28 VDC, with an electrical life of 100,000 operations at rated load and mechanical life of 10,000,000 operations. It is UL recognized (File No. E37066) and CSA certified (File No. LR20690), making it suitable as a common replacement relay for existing equipment requiring reliable load control.

Search Keywords: 2011484

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Deltrol Controls
Part No:
20114-84
Alias/AKA:
105-DPDT-10A-110VDC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
110 V
Contact Arrangement:
DPDT
Maximum Current Rating:
10 A
Mounting:
Socket
Termination Style:
8-Pin Circular Plug
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
10 KOhm

FREQUENTLY ASKED QUESTIONS

Is 20114-84 RoHS compliant?

Yes, 20114-84 is RoHS compliant.

What is the lead time for 20114-84?

The standard lead time for 20114-84 is approximately 8 days. In-stock quantities ship from Master Electronics.

IN STOCK: 56

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$19.15
10
$18.26
25
$17.72
50
$17.20
100
$15.82
250
$15.40
500 +
$15.20
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

20983-81

The 20983-81 is an 8-terminal, DPDT socket rated for 10A at 300 VAC, designed for DIN rail ...
