FFB0412VHN-F00 by delta thermal / emi / solenoids

FFB0412VHN-F00

Delta Thermal / EMI / Solenoids

DC Fans DC Axial Fan - 40x28mm - 12VDC ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Delta Electronics FFB DC Axial Fans are built for high performance and feature a dual blade as well as a high air flow rotating stator blade. Delta FFB standard DC axial fan series has a plastic impeller and frame, as well as Delta’s maintenance-free ball bearing system. FEATURES Bearing type - ball bearing Impeller and frame material - plastic (UL 94V-0) Lead wires UL 1007 AWG #24 or equivalent Red wire positive (+) Black wire negative (-) Voltage - Rated 12VDC Size / Dimension Square - 40mm L x 40mm H Width 28.00mm Air Flow 15.8 CFM (0.442m³/min) Bearing Type Ball Fan Type Tubeaxial Features Speed Sensor (Tach) Noise 45.0 dB(A) Power (Watts) 1.92W RPM 9500 RPM Termination 3 Wire Leads

Search Keywords: FFB0412VHNF00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
FFB0412VHN-F00
RoHS:
Yes
HTS:
8414591500
COO:
TH
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
576
Package Type:
Box
Category:
DC Fan
Dimension:
40 x 40 x 28 mm
Voltage Rating:
12 V
Power Rating:
1.92 W
Maximum Airflow:
15.7CFM
Noise Level:
45 dB
Tachometer Signal:
Yes
Special Features:
Tachometer Output
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

IN STOCK: 860

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 32 Weeks
