AFB0724VH-AF00 by delta thermal / emi / solenoids
Image is representational - see manufacturer specifications
Delta Thermal / EMI / Solenoids Authorized Distributor

AFB0724VH-AF00

Axial Square-70mm L x 70mm H x 25.4 mm W 24VDC 3 Wire Leads Speed Sensor (Tach) ...

View Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

AFB0724VH-AF00 is a DC brushless axial flow fan designed for efficient thermal management in electronic equipment. The fan operates at a rated voltage of 24 VDC with an operating range of 14.0 to 26.4 VDC, delivering a maximum air flow of 1.472 M³/MIN (51.97 CFM) at zero static pressure and a maximum air pressure of 10.99 mmHg2O at zero airflow. It features a two-phase, four-pole motor configuration running at 5500 RPM ±10% with low acoustic noise of 47.5 dB-A average, and incorporates two ball bearings for reliable long-term operation. The fan is constructed with UL 94V-0 plastic frame and impeller, includes locked rotor protection, and is rated for 70,000 hours of continuous operation at 40°C. It is commonly used in server cooling, industrial equipment, and telecommunications systems where reliable thermal management and low noise operation are essential.

Search Keywords: AFB0724VHAF00

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Delta Thermal / EMI / Solenoids
Part No:
AFB0724VH-AF00
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8414596590
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
162
Category:
DC Fan
Dimension:
70 x 70 x 25.4 mm
Voltage Rating:
24 V
Power Rating:
6.48 W
Maximum Airflow:
51.97 CFM
Noise Level:
47.5 dB
Special Features:
N/A
Termination:
Lead Wires
Housing Material:
Plastic
Operating Temperature:
-10 to 70 °C

FREQUENTLY ASKED QUESTIONS

Is AFB0724VH-AF00 RoHS compliant?

Yes, AFB0724VH-AF00 is RoHS compliant.

What is the lead time for AFB0724VH-AF00?

The standard lead time for AFB0724VH-AF00 is approximately 32 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 420

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 162

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
5
$28.98
50
$28.91
100
$28.84
162
$28.76
324
$15.18
486
$10.44
648 +
$10.23
Supplier's Standard Package
