F1500CA15 by curtis industries
Curtis Industries Authorized Distributor

F1500CA15

Power Line Filter 50Hz/60Hz 15A 250VAC Quick Connect Screw Mount ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

F1500CA15 is a high-performance RFI filter designed for single-phase power supply applications requiring electromagnetic interference suppression. It features an IEC connector on the line side and 0.250" quick-connect terminals on the load side, with a compact "L" circuit configuration that provides both common and differential mode filtering. The filter is rated for 15A at 250VAC (50/60 Hz) with a maximum ambient temperature of 40°C at rated current, and offers high-inductance design for greater attenuation across a wide frequency range. Minimum insertion loss specifications include 26 dB at 0.15 MHz (common mode) and 35 dB at 0.15 MHz (differential mode), with performance extending to 30 MHz. This filter is ideal for linear and switching power supply applications where cost-effective RFI suppression and compact form factor are essential.

Search Keywords: F1500CA15

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Curtis Industries
Part No:
F1500CA15
Unit of Measure:
Per Each
RoHS:
Yes
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Mounting:
Screw Mount
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
15 A
Operating Frequency:
50,60 Hz
Operating Temperature:
N/A
Dimension:
50.8 x 38.2 mm

FREQUENTLY ASKED QUESTIONS

Is F1500CA15 RoHS compliant?

Yes, F1500CA15 is RoHS compliant.

What is the lead time for F1500CA15?

The standard lead time for F1500CA15 is approximately 9 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 11

Can Ship immediately

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
1
$65.42
5
$63.35
10
$62.46
20
$61.57
50
$58.31
100 +
$57.46
