MP040 by cts corporation
Image is representational - see manufacturer specifications
CTS Corporation Authorized Distributor

MP040

Crystal 4MHz ±30ppm (Tol) ±50ppm (Stability) 20pF FUND 100Ohm 2-Pin HC-49 Thru-Hole Bulk ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

MP040 is a 4.0 MHz quartz crystal designed for fundamental mode operation with an 18 pF load capacitance, housed in a standard HC-49/U metal package. The crystal features an AT-cut design with a frequency tolerance of ±30 ppm at +25°C and frequency stability of ±50 ppm over the operating temperature range. It exhibits a series resistance of 100 O and a maximum shunt capacitance of 7.0 pF, with drive level capability of 100–1000 µW. The MP040 is ideal for applications in wireless communications, FPGA/microcontrollers, computer peripherals, and consumer electronics requiring stable timing references with proven reliability in commercial and industrial environments.

Search Keywords: MP040

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CTS Corporation
Part No:
MP040
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541600030
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Standard Frequency:
4 MHz
Load Capacitance:
20 pF
Frequency Tolerance:
±30 ppm
Supplier Package:
HC-49
Operating Temperature:
-20 to 70 °C

FREQUENTLY ASKED QUESTIONS

Is MP040 RoHS compliant?

Yes, MP040 is RoHS compliant.

What is the lead time for MP040?

The standard lead time for MP040 is approximately 15 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 2,875

Can Ship immediately

On Order: 5,000   can ship 10/8/26

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
100
$0.7517
300
$0.7072
1,000
$0.6583
2,500
$0.6211
5,000
$0.5069
7,500
$0.4930
10,000
$0.4537
15,000 +
$0.4407
Supplier's Standard Package
