Image is representational - see mfr. specs

6280-6PG-3DC

The 6280-6PG-3DC is a Mini-Con-X series 6-contact, field-installable cable end connector with #20 crimp-style pin contacts and a daisy chain grommet backshell. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 6280-6PG-3DC is a field-installable cable end connector from the Mini-Con-XÂ® series. It is configured with six #20 pin contacts that are gold-plated over nickel and designed for a crimp termination style. This connector features a Style 3 backshell with a "daisy chain" grommet, which has three internal diameters (.125", .188", and .250") to accommodate various cable sizes. The backshell provides a weathertight grommet grip and seal, complemented by an interfacial "O" ring for enhanced environmental protection. This connector is suitable for a wide range of indoor and outdoor industrial and electronic applications where a reliable and robust connection is required.

Product Highlights:

Potential Applications:

Search Keywords: 62806PG3DC

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Conxall

Part No:

6280-6PG-3DC

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694020

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
