102-1031-BL-00300 by cnc tech
CNC Tech Authorized Distributor

102-1031-BL-00300

USB Cable 2.0 - A Male To B Mini 5Pin 3M ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

102-1031-BL-00300 is a high-speed USB Revision 2.0 shielded cable assembly designed for reliable data and power transmission. The cable features 28 AWG single pair plus 28 AWG dual conductors with a 4-pin connector configuration (RED, WHITE, GREEN, BLACK pins on P1 and SHELL, DRAIN+BRAID, SHELL on P2). It is constructed with PE-LD insulation rated for 80°C operation at 30V maximum, and includes comprehensive electrical testing including 100% short/open verification, maximum conductor resistance of 2 Ohm, insulation resistance of 10 MO, and dielectric strength of 300V DC. The cable measures 230 mm in length with connector spacing of 110±10 mm and 130 mm dimensions, making it suitable for consumer electronics, computer peripherals, and industrial USB applications requiring shielded signal integrity.

Search Keywords: 1021031BL00300

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
CNC Tech
Part No:
102-1031-BL-00300
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544422000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Package Type:
BOX

FREQUENTLY ASKED QUESTIONS

Is 102-1031-BL-00300 RoHS compliant?

Yes, 102-1031-BL-00300 is RoHS compliant.

What is the lead time for 102-1031-BL-00300?

The standard lead time for 102-1031-BL-00300 is approximately 20 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 275

Can Ship immediately

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
10
$4.57
50
$4.19
100
$4.02
250
$3.80
500
$3.64
1,000
$3.47
2,500
$3.25
5,000 +
$3.16
