RA2425-D06 by carlo gavazzi
Image is representational - see manufacturer specifications
Carlo Gavazzi Authorized Distributor

RA2425-D06

Solid State Relay - SPST NO - 25 A - 280 VAC - Panel, Screw - Zero Crossing ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The RA2425-D06 is a 1-phase Solid State Relay with SPST-NO contact, NORYL GFN 1 black housing and nickel-plated aluminium base plate. This panel mount relay features zero crossing switching mode and screw terminals. The zero switching relay with ant parallel thyristor output is the most widely used industrial SSR due to its multiple application possibilities. The relay can be used for resistive, inductive and capacitive loads. The zero switching relay switches ON when the sine curve just crosses zero and switches OFF when the current crosses zero. Direct copper bonding technology 230VACrms Operational voltage 650Vp Blocking voltage ≤1.6Vrms On-state voltage drop 1.5kΩ Input impedance ≤1/2cycle Pick-up/drop-out response time -20 to 70°C Operating temperature range Applications Industrial

Search Keywords: RA2425D06

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Carlo Gavazzi
Part No:
RA2425-D06
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8535908085
COO:
MT
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
25(RMS) A
Output Device:
Thyristor
Input Type:
DC
Input Voltage:
32 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
45.5 x 58.2 x 30 mm

FREQUENTLY ASKED QUESTIONS

Is RA2425-D06 RoHS compliant?

Yes, RA2425-D06 is RoHS compliant.

What is the lead time for RA2425-D06?

The standard lead time for RA2425-D06 is approximately 12 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 42

Can Ship immediately

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$68.77
5
$66.28
20
$63.95
40
$62.27
60
$60.59
100
$58.09
260 +
$57.94
