DESCRIPTION

The PD30CND10NPRT is a diffuse-reflective photoelectric sensor designed for high-accuracy detection in a compact 10 x 30 x 20 mm housing. It operates on a supply voltage of 10 to 30 VDC and features a preset NPN output with a current rating of 100 mA. The sensor uses modulated red light (660 nm) and offers a programmable make or break switching function. Sensitivity is adjustable via a Teach-In function, which can also be controlled remotely from a PLC. With its IP67 protection rating and excellent EMC performance, this sensor is well-suited for applications where small size and flexible, high-accuracy detection are critical.
