563002D00000G by boyd laconia llc

563002D00000G

Boyd Laconia LLC

Heat Sink Passive TO-220 Vertical Thru-Hole Aluminum 13A°C/W Matte Tin ...

Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AAVID THERMALLOY part 563002D00000G is a high-quality heat sink designed for passive cooling of electronic components, specifically TO-220 packages. This vertical thru-hole heat sink is made from aluminum, ensuring excellent heat dissipation capabilities. With a thermal resistance of 13AA°C/W, it effectively transfers heat away from the component, preventing overheating and increasing overall reliability. The heat sink is finished with a matte tin coating, providing corrosion resistance and a professional appearance. Perfectly suited for a variety of applications, this heat sink is a reliable choice for efficient thermal management.

Search Keywords: 563002D00000G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Boyd Laconia LLC
Part No:
563002D00000G
Alias/AKA:
041743
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Device Cooled:
TO-2206707
Attachment Method:
Screw6706
Dimension:
25.4 x 12.7 x 29.976714mm
Thermal Resistance:
136717°C/W
Finish:
Matte Tin6710

IN STOCK: 0

MOQ for out of Stock Qty: 1500

Factory Lead-Time 9 Weeks

Qty
Unit Price
1,500
$6.12
3,000
$3.24
4,500
$2.22
6,000 +
$2.18
