SRR1210-221M by bourns
Image is representational - see mfr. specs

SRR1210-221M

Bourns

The SRR1210-221M is a shielded, surface-mount power inductor with an inductance of 220 µH. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SRR1210-221M is a shielded SMD power inductor designed for power supply applications. It provides an inductance of 220 µH with a ±20% tolerance, a maximum DC resistance of 315 mΩ, and a typical self-resonant frequency of 1.8 MHz. The component is rated for a saturation current (Isat) of 1.5 A and an RMS current (Irms) of 1.7 A. With an operating temperature range of -40°C to +125°C, this RoHS-compliant inductor is robust for various environments. It is well-suited for use in the input/output stages of DC/DC converters and power supplies for portable communication equipment, camcorders, and LCD TVs.

Search Keywords: SRR1210221M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SRR1210-221M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504500000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
250
Package Type:
REEL
Inductance:
220 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
1.7 A
Maximum DC Resistance:
0.315 Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Shielded

IN STOCK: 0

Minimum Order Quantity: 250

Multiple: 250

Factory Lead-Time 20 Weeks

Qty
Unit Price
250
$0.901
500
$0.783
1,000
$0.731
2,500
$0.685
5,000
$0.681
7,500
$0.678
10,000
$0.675
15,000 +
$0.671
