SRN8040-150M by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

SRN8040-150M

Inductor Power Semi-Shielded Wirewound 15uH 20% 100KHz 15Q-Factor Ferrite 2.4A 70mOhm DCR T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

SRN8040-150M is a semi-shielded power inductor from Bourns' SRN8040 series designed for high-current DC/DC converter applications. The inductor features a 15 µH inductance value with a tolerance of ±15%, a maximum DC resistance of 2.4 O, and a rated RMS current of 2.7 A, with saturation current of 2.7 A. It operates over a temperature range of -40°C to +125°C with a component height of 4 mm, making it suitable for compact power supply designs. The device is RoHS compliant and halogen-free, with a ferrite core and enameled copper wire construction. Common applications include notebook computers, digital video cameras, HDDs, cell phones, and LCD display televisions, where reliable power conversion and space efficiency are essential.

Search Keywords: SRN8040150M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SRN8040-150M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
REEL
Inductance:
15 uH
Type:
Power
Impedance:
N/A
Tolerance:
20 %
Technology:
Wirewound
Maximum DC Current:
2.4 A
Maximum DC Resistance:
0.07 Ohm
Operating Temperature:
-40 to 125 °C
Packaging:
Tape and Reel
Protection Style:
Semi-Shielded

FREQUENTLY ASKED QUESTIONS

Is SRN8040-150M RoHS compliant?

Yes, SRN8040-150M is RoHS compliant.

What is the lead time for SRN8040-150M?

The standard lead time for SRN8040-150M is approximately 16 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 0

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.2891
3,000
$0.2681
5,000
$0.2606
8,000
$0.2534
10,000
$0.2528
25,000
$0.2434
50,000 +
$0.2372
Reel Package
Log in for special pricing

Tools/3D Models

Product Guides
