SM91073AL-E
SM91073AL-E
In Stock: 3,533
Minimum Order: 3,000
VIEW PRODUCT
SM91072AL-E by bourns
Bourns Authorized Distributor

SM91072AL-E

The SM91072AL-E is an AEC-Q200 compliant, single-port 10/100 Base-T LAN transformer designed to meet IEEE 802.3u standards. ...

View Datasheet
RoHS Compliant
REEL Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The SM91072AL-E is an AEC-Q200 compliant 10/100 Base-T transformer designed for Ethernet applications. It meets IEEE 802.3u standards and features a turns ratio of 1:1 (±2%) for both transmit and receive channels, with a minimum Open Circuit Inductance (OCL) of 350 µH under an 8 mA DC bias. The device offers a low insertion loss of -1.1 dB maximum from 1-100 MHz and provides high isolation rated at 1500 Vrms. Due to its expanded operating temperature range of -40 to +125 °C and AEC-Q200 compliance, this transformer is well-suited for automotive and industrial applications requiring robust network connectivity.

Search Keywords: SM91072ALE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
SM91072AL-E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504312000
COO:
CN
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL

FREQUENTLY ASKED QUESTIONS

What replaces SM91072AL-E?

The recommended replacement for SM91072AL-E is SM91073AL-E from Bourns, available from Master Electronics.

Is SM91072AL-E RoHS compliant?

Yes, SM91072AL-E is RoHS compliant.

What is the lead time for SM91072AL-E?

The standard lead time for SM91072AL-E is approximately 16 days. In-stock quantities ship from Master Electronics.

  Possible Replacement options available.  See Alternatives

IN STOCK: 20

Ships today, if you order in

Buy all 20 in-stock or the regular minimum order quantity of 100

On Order: 3,000   can ship 9/28/26

Stock lot only: 20

Minimum Order Quantity: 100

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$3.223
100
$2.930
250
$2.880
500
$2.760
1,000
$2.660
3,000
$2.570
6,000
$2.560
9,000
$2.550
12,000 +
$2.540
Reel Package
Log in for special pricing Click for Quote Price Match Request
