6701-RC

Inductor High Current Toroid 10uH/5uH 15% 1KHz 11A 8mOhm DCR Pin ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
Certificate of Compliance

DESCRIPTION

The 6701-RC is a high-current toroid inductor designed for applications requiring low radiation and high current capacity. It features an inductance of 10 µH (±15% @ 1 kHz) with a maximum current rating of 11.0 A and a minimum inductance of 5 µH at rated current. The inductor is mounted on a UL 94V-0 rated header with fixed pins for easy PCB insertion, and exhibits a maximum DC resistance of 0.008 O. Operating over a temperature range of -55°C to +105°C, this component is ideal for power supply circuits, filtering applications, and other high-current electronic systems where compact size and reliable performance are essential.

Search Keywords: 6701RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
6701-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
TW
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
66
Inductance:
10(OCL)/5 uH
Type:
High current
Impedance:
N/A
Lead Pitch:
15.24 mm
Tolerance:
15 %
Technology:
Toroid
Maximum DC Resistance:
8 mOhm
Maximum DC Current:
11 A
Protection Style:
N/A
Packaging:
N/A
Life Cycle:
Discontinued

FREQUENTLY ASKED QUESTIONS

Is 6701-RC discontinued?

Yes, 6701-RC from Bourns is discontinued (end-of-life November 2015). Master Electronics is an authorized distributor and may have remaining stock or a recommended replacement for it.

Is 6701-RC RoHS compliant?

Yes, 6701-RC is RoHS compliant.

What is the lead time for 6701-RC?

The standard lead time for 6701-RC is approximately 21 weeks. In-stock quantities ship from Master Electronics.

  This product is discontinued, but still in stock

IN STOCK: 138

Ships today, if you order in

Price (USD)

Qty
Unit Price
1
$2.77
25
$2.71
50
$2.66
100
$2.60
500
$2.55
1,000 +
$2.50
