5900-470-RC by bourns
Image is representational - see manufacturer specifications
Bourns Authorized Distributor

5900-470-RC

High Current RF Choke - Bobbin Core - 47uH - 1KHz - Ferrite Core - 3.1A - 45mOhm. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 5900-470-RC is high current RF choke bobbin core with ferrite core and inductance of 1mh. Main features are high current capacity, VW-1 rated shrink tubing to cover winding and dielectric strength 2500 Vrms. Operating temperature ranges from -40°C to 125°C.

Search Keywords: 5900470RC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
5900-470-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
864
Package Type:
TRAY
Inductance:
47 uH
Type:
High Current RF Choke
Impedance:
N/A
Lead Pitch:
N/R
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
45 mOhm
Maximum DC Current:
3.1 A
Protection Style:
N/A
Packaging:
N/A

FREQUENTLY ASKED QUESTIONS

Is 5900-470-RC RoHS compliant?

Yes, 5900-470-RC is RoHS compliant.

What is the lead time for 5900-470-RC?

The standard lead time for 5900-470-RC is approximately 18 days. In-stock quantities ship from Master Electronics.

IN STOCK: 602

Ships today, if you order in

On Order: 1,146   can ship 11/19/26

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 216

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
25
$1.78
50
$1.73
100
$1.72
216
$1.71
432
$1.70
648
$1.69
864 +
$1.68
Supplier's Standard Package
