3009P-1-103LF
BournsRes Cermet Trimmer 10K Ohm 10% 0.75W(3/4W) 15(Elec)Turn 2.36mm (20.57 X 4.83 X 8.98mm) Pin Thru-Hole Tube
RoHS Compliant
TUBE Packaging
Certificate of Compliance Guarantee
DESCRIPTION
Res Cermet Trimmer 10K Ohm 10% 0.75W(3/4W) 15(Elec)Turn 2.36mm (20.57 X 4.83 X 8.98mm) Pin Thru-Hole Tube
Search Keywords: 3009P1103LF
SPECIFICATIONS
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3009P-1-103LF
RoHS:
Yes
HTS:
8533408050
COO:
HU
ECCN:
EAR99
Supplier Standard Pack
100
Package Type:
TUBE
Mounting:
Through Hole
Number of Turns:
15(Elec) Turns
Termination Style:
Pin
Power Rating:
0.75 (3/4) W
Resistance Value:
10 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
20.57 x 4.83 x 8.98 mm
Operating Temperature:
-55 to 150 °C
Switch Option:
No
Number of Elements:
1
IN STOCK: 400
Can Ship immediately
Minimum Order: 100
Multiple: 100
Factory Lead-Time 12 Weeks
Qty
Unit Price
100
$1.19
300
$1.18
500
$1.17
1,000
+
$1.16
Please Note:
Tariffs may apply for U.S. shipments
Tools/3D Models
Product Guides
Datasheet
China RoHS/CRHOS3009
