3006P-1-502ZLF by bourns

3006P-1-502ZLF

Bourns

Res Cermet Trimmer 5K Ohm 10% 0.75W(3/4W) 15(Elec)Turn 2.54mm (26.67 X 7.92mm) Pin Panel Mount/Through Hole Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The BOURNS 3006P-1-502ZLF is a precision cermet trimmer designed for use in electronic circuits. With a resistance of 5K ohms and a tolerance of 10%, this trimmer is capable of handling up to 0.75W (3/4W) of power. Featuring 15 electrical turns for precise adjustments, it is panel mount/through hole compatible with a pin spacing of 2.54mm. The compact size of 26.67 x 7.92mm allows for easy installation in a variety of applications. This trimmer is supplied in a tube packaging for convenient storage and handling.

Search Keywords: 3006P1502ZLF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
3006P-1-502ZLF
RoHS:
Yes
HTS:
8533408050
COO:
TW
ECCN:
EAR99
Supplier Standard Pack  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Mounting:
Panel Mount/Through Hole
Number of Turns:
15(Elec) Turns
Termination Style:
Pin
Power Rating:
0.75 (3/4) W
Resistance Value:
5 KOhm
Tolerance:
10 %
Temperature Coefficient:
±100 ppm/°C
Dimension:
26.67 x 7.92 mm
Operating Temperature:
-55 to 125 °C
Switch Option:
No
Number of Elements:
1

IN STOCK: 295

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 12 Weeks

Qty
Unit Price
5
$4.635
50
$3.828
100
$3.458
300
$3.314
500
$3.150
1,000
$2.986
2,500
$2.971
5,000 +
$2.956
