1140-471K-RC

High Current RF Choke Bobbin Core 470uH 10% 1KHz Ferrite 4.9A 114mOhm DCR RDL ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The 1140-471K-RC is a high-current choke inductor designed for demanding power conversion and filtering applications. It features an inductance of 470 µH (±10%) at 1 kHz with a maximum DC resistance of 0.114 O, enabling efficient energy storage and current smoothing in high-current circuits. The component utilizes an epoxy-coated ferrite bobbin core with VW-1 rated shrink tubing, providing robust mechanical and electrical protection. With a rated current capacity of 4.9 A (Series A) and saturation current of 9.5 A, it delivers very high current handling capability while maintaining low losses. The choke operates reliably across a temperature range of -55°C to +105°C and features self-leaded construction with fixed lead spacing and a center hole for mechanical mounting. These characteristics make it ideal for switching power supplies, DC-DC converters, and other applications requiring high-current filtering and inductance with minimal thermal rise.

Search Keywords: 1140471KRC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Bourns
Part No:
1140-471K-RC
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504508000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
70
Package Type:
OTHER
Inductance:
470 uH
Type:
High Current RF Choke
Lead Pitch:
29.21 mm
Tolerance:
10 %
Technology:
Bobbin Core
Maximum DC Resistance:
114 mOhm
Maximum DC Current:
4.9 A

FREQUENTLY ASKED QUESTIONS

Is 1140-471K-RC RoHS compliant?

Yes, 1140-471K-RC is RoHS compliant.

What is the lead time for 1140-471K-RC?

The standard lead time for 1140-471K-RC is approximately 9 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 190

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
5
$8.73
25
$8.29
70
$8.10
140
$7.82
280
$7.72
560
$7.63
1,050 +
$7.53
