09-0571-00-08
M16 IP40 Male cable connector, Contacts: 8 (08-a), 3.0-6.0mm, unshielded, solder, IP40 ...
DESCRIPTION
The 09-0571-00-08 is an M16 male cable connector from the series 680 designed for miniature industrial applications requiring reliable signal and power transmission. It features 8 contacts (08-a) with straight connector pins, solder termination, and a screw-type locking system, accommodating cable cross-sections of 0.75 mm² (AWG 18) with cable outlet diameters of 3.0–6.0 mm. Electrically, the connector is rated for 60 V nominal with a 500 V impulse rating, carries 5.0 A per contact, and maintains insulation resistance of =10¹° O; it operates across -40 °C to +85 °C and withstands over 500 mating cycles. The unshielded design complies with DIN EN 61076-2-106 and achieves IP40 protection, making it suitable for plant engineering, control systems, and electrical equipment where robust, compact connectivity is required.
Search Keywords: 0905710008
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is 09-0571-00-08 RoHS compliant?
Yes, 09-0571-00-08 is RoHS compliant.
What is the lead time for 09-0571-00-08?
The standard lead time for 09-0571-00-08 is approximately 6 weeks. In-stock quantities ship from Master Electronics.
IN STOCK: 35
Ships today, if you order in
Manufacturer Stock: 174 can ship 10/19/26
Minimum Order Quantity: 5
Factory Lead-Time 6 Weeks can ship 11/16/26
