P260S-D1AS3CB5K

Res Conductive Plastic POT 5K Ohm 10% 0.5W(1/2W) 1(Elec)/1(Mech)Turns 3.2mm (38.8 X 13.3 X 12.7mm) Pin Panel Mount/Through Hole Box/Tray ...

View Datasheet
RoHS Compliant
Tray Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

P260S-D1AS3CB5K is a 12.7mm (1/2") square rotary panel potentiometer with an integrated rotary switch module, featuring side adjust configuration with PCB leads. It incorporates a metal shaft and bushing construction with sealed/dust proof design and offers a 1,000,000 cycle life rating. The potentiometer supports resistance ranges from 500O to 1MO (for "B" taper) or 2KO to 1MO (for other tapers) with ±10% standard resistance tolerance, and can accommodate up to 5 gangs with the rotary switch. This component meets MIL-PRF-94 requirements and is RoHS compliant, making it ideal for professional audio applications including electric guitars, amplifiers, mixers, drum machines, and synthesizers.

Search Keywords: P260SD1AS3CB5K

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
BI Technologies/TT Electronics
Part No:
P260S-D1AS3CB5K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408050
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
840
Package Type:
Tray
Mounting:
Panel Mount/Through Hole11434
Number of Turns:
1(Elec),1(Mech) Tur ns
Termination Style:
Pin11449
Power Rating:
0.5 (1/2) W
Resistance Value:
5 KOhm
Tolerance:
1011450%
Dimension:
38.8 x 13.3 x 12.711440mm
Operating Temperature:
-55 to 125 °C
Switch Option:
Yes11446
Number of Elements:
111435

FREQUENTLY ASKED QUESTIONS

Is P260S-D1AS3CB5K RoHS compliant?

Yes, P260S-D1AS3CB5K is RoHS compliant.

What is the lead time for P260S-D1AS3CB5K?

The standard lead time for P260S-D1AS3CB5K is approximately 32 weeks. In-stock quantities ship from Master Electronics.

IN STOCK: 1,635

Can Ship immediately

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 420

Factory Lead-Time 32 Weeks

Price (USD)

Qty
Unit Price
5
$13.89
100
$8.97
250
$8.60
420
$8.51
840
$8.43
1,260
$8.35
1,680 +
$8.26
