8760MN-GRY-100

The 8760MN-GRY-100 is a single-pair 18 AWG stranded tinned copper cable featuring polypropylene insulation, a Beldfoil® shield, and a gray PVC jacket. ...

Datasheet

RoHS Compliant

Reel Packaging

Certificate of Compliance Guarantee

DESCRIPTION

The 8760MN-GRY-100 is a single-pair 18 AWG shielded cable designed for indoor electronic applications. It is constructed with stranded (41x34) tinned copper conductors, polypropylene insulation, and an overall Beldfoil® shield that provides 100% coverage for signal integrity. Key electrical characteristics include a UL voltage rating of 300V RMS, a nominal conductor-to-conductor capacitance of 76.9 pF/ft, and a nominal conductor DCR of 6.5 Ohm/1000ft. The cable features a durable gray PVC jacket and is rated for an operating temperature range of -20°C to +80°C. This cable is ideal for applications requiring reliable, shielded signal transmission in compliance with UL AWM Style 2937 and NFPA 79 standards.

Product Highlights:

Potential Applications:

Search Keywords: 8760MNGRY100

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Belden

Part No:

8760MN-GRY-100

Alias/AKA:

8760MN-008100

Unit of Measure:

Per Foot

RoHS:

Yes

COO:

ECCN:

EAR99

Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
