PRQE75W-E12-S15-D
Bel Power SolutionsDC-DC Converter - 15 VDC - 5 A - 75 W - 9-75 VDC Input Range - DIP ...
DESCRIPTION
PRQE75W-E12-S15-D is a 75 W isolated DC-DC converter housed in a ¼-brick package with industry-standard pin-out, designed for demanding industrial and transportation applications. The converter accepts an ultra-wide input voltage range of 9–75 V (nominal 36 V) and delivers a regulated 15 V output at a maximum current of 5.0 A, with typical efficiency of 90% at 36 V input. It features comprehensive protection including output short circuit, over-current, over-voltage, and over-temperature protection, along with 3000 Vdc input-to-output isolation and 100 MO minimum isolation resistance. The unit operates reliably across an ambient temperature range of -40°C to +105°C, meets UL/EN/IEC 62368-1 safety standards, and is designed to comply with EN 61373, EN 45545-2, and EN 50155 with external components. With a maximum capacitive load of 10,000 µF, voltage accuracy of ±1.0%, and line/load regulation of ±0.2%, this converter is ideal for railway, industrial control, and telecommunications systems requiring high reliability and wide input voltage tolerance.
Search Keywords: PRQE75WE12S15D
SPECIFICATIONS
IN STOCK: 11
Can Ship immediately
MOQ for In Stock Qty: 2
MOQ for out of Stock Qty: 2
Factory Lead-Time 14 Weeks
Datasheet
