A-DF-09-LL/Z by assmann wsw components
Image is representational - see manufacturer specifications
Assmann WSW Components Authorized Distributor

A-DF-09-LL/Z

Conn D-Subminiature F 9 POS Solder Cup ST Panel Mount 9 Terminal 1 Port ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

The Assmann WSW Components A-DF-09-LL/Z is a D-Subminiature connector featuring a solder cup termination for easy and reliable connections. This connector is designed with a 9 position configuration, making it suitable for a variety of applications. With a panel mount design, it can be securely fastened to a surface for a stable connection. The connector has 9 terminals and 1 port, ensuring efficient and organized wiring. Whether you need to create a data link, transmit signals, or control devices, the A-DF-09-LL/Z is a reliable choice for your connectivity needs.

Search Keywords: ADF09LLZ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Assmann WSW Components
Part No:
A-DF-09-LL/Z
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8544422000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
TRAY
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Panel Mount
Gender:
F
Termination Method:
Solder Cup
Shell Size:
E
Number of Contacts:
9
Contact Plating:
N/A
Operating Temperature:
-55 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is A-DF-09-LL/Z RoHS compliant?

Yes, A-DF-09-LL/Z is RoHS compliant.

What is the lead time for A-DF-09-LL/Z?

The standard lead time for A-DF-09-LL/Z is approximately 15 days. In-stock quantities ship from Master Electronics.

IN STOCK: 6,262

Can Ship immediately

On Order: 550   can ship 10/21/26

Minimum Order Quantity: 100

Multiple: 50

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
100
$0.3714
500
$0.3230
2,500
$0.2905
5,000
$0.2891
7,500
$0.2884
25,000
$0.2877
50,000 +
$0.2869
Log in for special pricing Click for Quote Price Match Request
