13602480

Name: 13602480 Aptiv Formerly Delphi Rectangular
Brand: Aptiv Formerly Delphi
SKU: 59821369
Availability: InStock

The 13602480 is a two-piece, tangless APEX® 6.35 series terminal designed for high-current automotive applications. ...

View Datasheet Ask the Datasheet

RoHS Compliant

BULK Packaging

Certificate of Compliance

DESCRIPTION

The 13602480 is an APEX® 6.35 series box and blade terminal designed for heavy-duty, high-power connections. It features a two-piece construction with an integrated floating spring made of beryllium copper or copper nickel silicon for reliable performance. This terminal family supports a wide wire gauge range from 20 to 8 AWG (0.5 to 8.0 mm²), can handle a maximum current of 55 A, and operates at temperatures up to 125°C. Key performance characteristics include a contact resistance of less than 2 mΩ and vibration resistance up to 20 G. Available in both male and female genders with various plating options, it is well-suited for unique high-current and high-power applications.

Product Highlights:

Potential Applications:

Search Keywords: 13602480

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Aptiv (formerly Delphi)

Part No:

13602480

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538900100

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
