12092839
Connector - 4 Contact - Male - M/P 150 Sealed ...
DESCRIPTION
The 12092839 is a versatile low-voltage connector terminal designed for automotive electrical systems, featuring a two-piece box-and-blade construction with tangless/lanceless locking mechanism and APEX® cavity technology. The terminal supports multiple configurations with wire gauge ranges from 16 to 28 AWG (0.08 to 1.5 mm²), available in both female and male genders with tin (Sn) or gold (Au) plating options. Key electrical characteristics include contact resistance below 0.5 to 2 mO depending on configuration, contact mating forces below 3.5 to 5 N, and current ratings up to 40 A with maximum operating temperature of 150°C and vibration tolerance of 30 G. The terminal is compatible with multiple housing series including APEX® 150 Sealed, APEX® Mixed Series, and APEX® ErgoMate™ Series, making it suitable for diverse automotive wiring harness applications requiring reliable sealed or unsealed connections.
Search Keywords: 12092839
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is 12092839 RoHS compliant?
Yes, 12092839 is RoHS compliant.
What is the lead time for 12092839?
The standard lead time for 12092839 is approximately 8 weeks. In-stock quantities ship from Master Electronics.
IN STOCK: 245
Can Ship immediately
Minimum Order Quantity: 25
Factory Lead-Time 8 Weeks
Price (USD)
