10762802
2.8 Clean Body APEX Female SN Unsealed Terminal ...
DESCRIPTION
The 10762802 is an APEX® 2.8 series unsealed female terminal designed for high-current power distribution in automotive and industrial applications. It features two-piece construction with an integrated floating spring made of beryllium copper or copper nickel silicon, supporting wire sizes from 12 to 10 AWG (4.0 to 6.0 mm²) with tin (Sn) plating and optional gold (Au) plating. The terminal delivers a contact resistance below 2 mO, a contact mating force below 5 N, and an unmating force below 2 N, ensuring reliable low-force connections. With a tangless/lanceless locking mechanism and APEX® cavity design, it is compatible with APEX® 2.8 unsealed and sealed series housings as well as mixed and ErgoMate™ series housings. This terminal is ideal for heavy-duty applications requiring highest current ratings and low contact resistance in sealed or unsealed connector assemblies.
Search Keywords: 10762802
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is 10762802 RoHS compliant?
Yes, 10762802 is RoHS compliant.
What is the lead time for 10762802?
The standard lead time for 10762802 is approximately 10 days. In-stock quantities ship from Master Electronics.
IN STOCK: 24,000
Can Ship immediately
Minimum Order Quantity: 2000
Multiple: 2000
Factory Lead-Time 10 Weeks
Product Drawing
Datasheet
