IRR3F422
APEM IRR3F422 Pushbutton Switch, SPST, Off-(On), 250 V, 48 V, 200 mA, Wire Leaded ...
DESCRIPTION
IRR3F422 is a sealed illuminated pushbutton switch from the IR series designed for panel-mounted applications with a 16 mm round bushing and momentary action. It features flying lead terminals with integrated LED capability, offering IP67 front panel sealing and tactile feedback with a flat round actuator. The switch is rated for gold-plated silver contacts with a maximum current/voltage rating of 200 mA at 48 VDC (500,000 cycles) or 5 A at 28 VDC (70,000 cycles), with an initial contact resistance of 100 mO maximum and dielectric strength of 1,500 Vrms. Operating across a temperature range of -40°C to +85°C with shock resistance of 100 g and vibration resistance of 10-500 Hz at 10 g, this switch is ideal for industrial control panels, instrumentation, and applications requiring reliable illuminated feedback in harsh environments.
Search Keywords: IRR3F422
SPECIFICATIONS
FREQUENTLY ASKED QUESTIONS
Is IRR3F422 RoHS compliant?
Yes, IRR3F422 is RoHS compliant.
What is the lead time for IRR3F422?
The standard lead time for IRR3F422 is approximately 10 weeks. In-stock quantities ship from Master Electronics.
IN STOCK: 21
Can Ship immediately
MOQ for out of Stock Qty: 7
Factory Lead-Time 10 Weeks
