Image is representational - see manufacturer specifications
6352
Conn Housing RCP 2 POS Crimp ST Cable Mount Red ...
RoHS Compliant
Certificate of Compliance
DESCRIPTION
The 6352 is a red SBX®350 hermaphroditic connector housing manufactured by Anderson Power Products, designed for high-current power distribution applications. It features a polycarbonate (PC) construction and is rated for 120 amperes wire-to-wire current (UL 1977) with a voltage rating of 600V AC/DC, supporting wire sizes from 16 to 6 AWG (1.3 to 13.3 mm²). The connector offers superior electrical performance with an average mated contact resistance of 0.200 milliohms and supports up to 10,000 mating cycles with silver-plated contacts. Operating over a temperature range of -20°C to +105°C (-4°F to +221°F), the 6352 is commonly used in alternate energy systems, power electronics, electric vehicles, telecommunications, and industrial applications where reliable high-current connections are essential.
Search Keywords: 6352
SPECIFICATIONS
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Anderson Power Products
Part No:
6352
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
US
ECCN:
EAR99
Supplier Standard Pack:
1
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Termination Method:
Crimp
Number of Contacts:
2
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Operating Temperature:
N/A
FREQUENTLY ASKED QUESTIONS
Is 6352 RoHS compliant?
Yes, 6352 is RoHS compliant.
What is the lead time for 6352?
The standard lead time for 6352 is approximately 6 days. In-stock quantities ship from Master Electronics.
IN STOCK: 84
Can Ship immediately
Factory Lead-Time 6 Weeks
Price (USD)
Qty
Unit Price
1
$27.16
10
$20.57
25
$19.05
50
$18.09
100
$17.23
250
$16.15
500
+
$15.38
