AT16-18PB-PM11

Name: AT16-18PB-PM11 Amphenol Sine Systems Rectangular
Brand: Amphenol Sine Systems
SKU: 55829573
Availability: InStock

18 Position Panel Mount Receptacle, Keyed B, Black ...

View Datasheet

RoHS Compliant

BOX Packaging

Certificate of Compliance

DESCRIPTION

The AT16-18PB-PM11 is an 18-position receptacle connector with pin configuration, part of the AT Series™ heavy-duty multi-pin thermoplastic connector family designed for demanding industrial environments. It features Size 16 contacts (14-20 AWG wire range) with a maximum current rating of 13A at 250V, and is available with optional keying configurations and PanelMate™ AT mounting. The connector incorporates superior front and rear environmental seals with silicone rubber sealing material, achieving IP68/IP69K protection in mated condition, along with an integrated latch for definitive electrical and mechanical connection. Operating reliably across -55°C to +125°C with mating cycle durability exceeding 100 cycles, the connector delivers exceptional shock resistance (50 g's per axis) and vibration tolerance (20 g's maximum acceleration at 10-2000 Hz sine sweep). This connector is ideal for heavy-duty, transportation, marine, diagnostic, and alternative energy applications where robust interconnect performance and environmental protection are critical.

Product Highlights:

Potential Applications:

Search Keywords: AT1618PBPM11

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AT16-18PB-PM11

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538908180

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
