AT06-3S-EC01 by amphenol sine systems
Image is representational - see manufacturer specifications
Amphenol Sine Systems Authorized Distributor

AT06-3S-EC01

3-Way Plug, Female Connector with End Cap, Grey ...

View Datasheet Ask the Datasheet
RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
Certificate of Compliance

DESCRIPTION

AT06-3S-EC01 is a 6-position heavy-duty thermoplastic connector from the AT Series™ line designed for industrial applications requiring robust environmental protection. The connector features IP67, IP68, and IP69K ratings in mated condition, providing dust-tight sealing and water resistance ranging from 1 meter immersion for 30 minutes (IP67) to high-pressure waterproof protection at multiple angles (IP69K). It is rated for 13A current capacity and incorporates an integral latching system that ensures definitive electrical and mechanical connections. The thermoplastic housing offers excellent UV resistance and superior environmental seal retention capabilities, making it suitable for harsh industrial environments, outdoor installations, and applications requiring reliable long-term performance in demanding conditions.

Search Keywords: AT063SEC01

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol Sine Systems
Part No:
AT06-3S-EC01
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908180
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1100
Package Type:
EACH
Type:
Housing
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
M
Pitch:
N/A
Termination Method:
Crimp
Number of Contacts:
3
Maximum Voltage Rating:
N/A
Maximum Current Rating:
13 A
Operating Temperature:
-55 to 125 °C

FREQUENTLY ASKED QUESTIONS

Is AT06-3S-EC01 RoHS compliant?

Yes, AT06-3S-EC01 is RoHS compliant.

What is the lead time for AT06-3S-EC01?

The standard lead time for AT06-3S-EC01 is approximately 12 days. In-stock quantities ship from Master Electronics.

IN STOCK: 1,629

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
25
$1.121
250
$0.976
500
$0.920
1,100
$0.839
3,300
$0.797
5,500
$0.788
7,700
$0.786
11,000 +
$0.784
Supplier's Standard Package
