AT04-12PA-BM01

Name: AT04-12PA-BM01 Amphenol Sine Systems Headers PCB Receptacles
Brand: Amphenol Sine Systems
SKU: 49187410
Availability: InStock

12 Position PCB Flange Mount Receptacle, Pin, Gold Plated Contacts Included, No Potting, Gray ...

View Datasheet Ask the Datasheet

RoHS Compliant

EACH Packaging

Certificate of Compliance

DESCRIPTION

AT04-12PA-BM01 is a 12-position PCB receptacle connector featuring a flangeless design with 180° straight pin orientation and snap-fit mounting capability. The connector utilizes Size 16 contacts with gold plating and is rated for 13A at 250V operating voltage. It incorporates a thermoplastic housing with silicone rubber sealing material, achieving IP67 and IP69K protection ratings in mated condition, and maintains insulation resistance of 1000 megohms minimum at 25°C. The connector operates reliably across a temperature range of -55°C to +125°C and withstands 100 mating cycles with thermal shock resistance through 10 cycles at temperature extremes. This product is ideal for sealed industrial environments including HVAC systems, heavy equipment, transportation, and boating applications where environmentally-sealed, compact connectivity is required.

Product Highlights:

Potential Applications:

Search Keywords: AT0412PABM01

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Amphenol Sine Systems

Part No:

AT04-12PA-BM01

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694040

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
