APH-BNCJ-HDBNCP by amphenol rf
Image is representational - see mfr. specs

APH-BNCJ-HDBNCP

Amphenol RF

Conn BNC Adapter PL/F 0Hz to 3GHz 75Ohm ST Gold Bag ...

Datasheet
RoHS Compliant
BAG Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The APH-BNCJ-HDBNCP is a 75-ohm BNC plug to HD-BNC jack adapter designed to interface between standard BNC and high-density BNC connectors in RF and microwave systems. It features a 75-ohm impedance with a frequency range of DC to 3 GHz and a minimum return loss of -25 dB, ensuring excellent signal integrity across the operating bandwidth. The connector is constructed with brass and nickel-plated body components, beryllium copper contacts with gold plating, and PTFE insulation, providing durability and reliable performance over a temperature range of -65°C to +165°C with a minimum mechanical durability of 500 mating cycles. This adapter is ideal for test equipment, instrumentation, and RF systems where impedance matching and signal fidelity are critical requirements.

Search Keywords: APHBNCJHDBNCP

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Amphenol RF
Part No:
APH-BNCJ-HDBNCP
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BAG
Type:
BNC Adapter
Impedance:
75 Ohm
Operating Frequency:
0 to 3 Hz to GHz
Gender:
PL/F
Mounting:
N/A
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
-65 to 165 °C
Dimension:
29.32 x 12 mm

IN STOCK: 55

Can Ship immediately

Manufacturer Stock: 65   can ship 6/22/26

Factory Lead-Time 13 Weeks can ship 9/7/26

Price (USD)

Qty
Unit Price
1
$47.39
5
$45.74
10
$38.49
25
$35.74
50
$34.03
100
$32.41
250 +
$30.31
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
